Sense
Key
ASC
ASCQ
Description
Command
Aborted
(0Bh)
3Fh
0Fh
ECHO
buffer
overwritten
43h
00h
SCSI
message
error
47h
00h
SCSI
parity
error
49h
00h
SCSI
invalid
message
4Eh
00h
Overlapped
command
attempt
Chapter
7.
Sense
Keys,
ASC,
and
ASCQ
7-5
