Dell PowerVault TL2000 Reference Guide

TL4000 Tape Library Element Addressing
Table 2-3. TL4000 Tape Library SCSI Element Types and Element Addresses
Element Type Element Address Range
Media Transport Element (MTE) 1 (0x01)
I/O Station Element (IEE) 16 (0x10), 17 (0x11), 18 (0x12)
Data Transfer Element (DTE) 256 (0x100), 257 (0x101)
Storage Element (STE) 4096 (0x1000) - 4139 (0x102B)
Table 2-4. TL4000 Tape Library SCSI element addresses for I/O Station, storage slots, and drive slot
Upper Left Magazine
⇐ Front of TL4000 Tape Library
Library
Rear Panel
Upper Right Magazine
Front of TL4000 Tape Library ⇒
Slot 17
4112
(0x1010)
Slot 18
4113
(0x1011)
Slot 19
4114
(0x1012)
Slot 20
4115
(0x1013)
Drive 2
257
(0x101)
Slot 44
4139
(0x102B)
Slot 43
4138
(0x102A)
Slot 42
4137
(0x1029)
Slot 41
4136
(0x1028)
Slot 13
4108
(0x100C)
Slot 14
4109
(0x100D)
Slot 15
4110
(0x100E)
Slot 16
4111
(0x100F)
Slot 40
4135
(0x1027)
Slot 39
4134
(0x1026)
Slot 38
4133
(0x1025)
Slot 37
4132
(0x1024)
Slot 9
4104
(0x1008)
Slot 10
4105
(0x1009)
Slot 11
4106
(0x100A)
Slot 12
4107
(0x100B)
Slot 36
4131
(0x1023)
Slot 35
4130
(0x1022)
Slot 34
4129
(0x1021)
Slot 33
4128
(0x1020)
Lower Left Magazine Drive 1
256
(0x100)
Lower Right Magazine
I/O Slot 3
18
(0x12)
Slot 7
4102
(0x1006)
Slot 8
4103
(0x1007)
DCS* Slot 32
4127
(0x101F)
Slot 31
4126
(0x101E)
Slot 30
4125
(0x101D)
Slot 29
4124
(0x101C
I/O Slot 2
17
(0x11)
Slot 4
4099
(0x1003)
Slot 5
4100
(0x1004)
Slot 6
4101
(0x1005)
Slot 28
4123
(0x101B)
Slot 27
4122
(0x101A)
Slot 26
4121
(0x1019)
Slot 25
4120
(0x1018)
I/O Slot 1
16
(0x10)
Slot 1
4096
(0x1000)
Slot 2
4097
(0x1001)
Slot 3
4098
(0x1002)
Slot 24
4119
(0x1017)
Slot 23
4118
(0x1016)
Slot 22
4117
(0x1015)
Slot 21
4116
(0x1014)
* Dedicated Cleaning Slot
2-6 TL2000 and TL4000 SCSI Reference

Dell PowerVault TL2000 Specifications

General

Number of Drives	1 or 2
Number of Slots	24
Type	Tape Library
Drive Types	LTO-4, LTO-5, LTO-6
Interface	SAS, Fibre Channel
Dimensions	8.68 in (22.05 cm) x 19.0 in (48.26 cm) x 30.0 in (76.2 cm)
Tape Drive Compatibility	LTO-4, LTO-5, LTO-6
Power Supply	Redundant power supplies optional
Operating Temperature	50°F to 95°F (10°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
