Dell PowerVault TL2000 Reference Guide

TL2000 Tape Library Element Addressing
Table 2-1. TL2000 Tape Library SCSI Element Types and Element Address Ranges
Element Type Element Address Range
Media Transport Element (MTE) 1 (0x01)
I/O Station Element (IEE) 16 (0x10)
Data Transfer Element (DTE) 256 (0x100)
Storage Element (STE) 4096 (0x1000) - 4117 (0x1015)
Table 2-2. TL2000 Tape Library SCSI element addresses for I/O Station, storage slots, and drive slot
Left Magazine
⇐ Front of TL2000 Tape Library
Library
Rear Panel
Right Magazine
Front of TL2000 Tape Library ⇒
Slot 8
(4103)
Slot 9
(4104)
Slot 10
(4105)
Slot 11
(4106)
Drive 1
256
(0x100)
Slot 23
(4118)
Slot 22
(4117)
Slot 21
(4116)
Slot 20
(4115)
Slot 4
(4099)
Slot 5
(4100)
Slot 6
(4101)
Slot 7
(4102)
Slot 19
(4114)
Slot 18
(4113)
Slot 17
(4112)
Slot 16
(4111)
I/O Station Slot 1
(4096)
Slot 2
(4097)
Slot 3
(4098)
Slot 15
(4110)
Slot 14
(4109)
Slot 13
(4108)
Slot 12
(4107)
Chapter 2. Library Features 2-5

Dell PowerVault TL2000 Specifications

General

Number of Drives	1 or 2
Number of Slots	24
Type	Tape Library
Drive Types	LTO-4, LTO-5, LTO-6
Interface	SAS, Fibre Channel
Dimensions	8.68 in (22.05 cm) x 19.0 in (48.26 cm) x 30.0 in (76.2 cm)
Tape Drive Compatibility	LTO-4, LTO-5, LTO-6
Power Supply	Redundant power supplies optional
Operating Temperature	50°F to 95°F (10°C to 35°C)
Non-operating Temperature	-40°F to 140°F (-40°C to 60°C)
