Dell Precision 7550 - Installing the Primary M.2 SSD Module

Installing the primary M.2 SSD module
Prerequisites
NOTE: For computers shipped with M.2 2280 or 2230 SSD installed in slot 3 and/or slot 5.
If you are replacing a component, remove the existing component before performing the installation procedure.
About this task
The figure indicates the location of the primary M.2 SSD and provides a visual representation of the installation procedure.
Steps
1. For M.2 2280 SSD:
a. Place the M.2 SSD onto its slot on the computer.
b. Replace the (M2x3) screw to secure the M.2 SSD to the computer.
