4. Install the keyboard.
5. Install the keyboard lattice.
6. Install the WLAN card.
7. Install the WWAN card.
8. Install the secondary memory.
9. Install the SIM card.
10. Install the primary M.2 SSD.
11. Install the inner frame.
12. Install the battery.
13. Install the base cover.
14. Install the secondary M.2 SSD.
15. Install the SSD door.
16. Install the SD card.
17. Follow the procedure in after working inside your computer.
GPU card
Removing the GPU card
Prerequisites
1. Follow the procedure in before working inside your computer.
2. Remove the SD card.
3. Remove the SSD door.
4. Remove the secondary M.2 SSD.
5. Remove the base cover.
6. Remove the battery.
7. Remove the primary M.2 SSD.
8. Remove the SIM card.
9. Remove the secondary memory.
10. Remove the WWAN card.
11. Remove the WLAN card.
12. Remove the keyboard lattice.
13. Remove the keyboard.
14. Remove the GPU power cable.
15. Remove the primary memory.
16. Remove the heat-sink assembly.
17. Remove the inner frame.
18. Remove the system board.
About this task
The figure indicates the location of the system board and provides a visual representation of the removal procedure. Images to be
uploaded in the next review cycle.
NOTE: For discrete models shipped with GPU card:
Steps
1. Remove the three (M2x5) screws that secures the GPU card to the palmrest.
2. Remove the GPU card from the computer.
Disassembly and reassembly
67
