Dell S4128F-ON Series User Manual

• S4100–ON Series (S4128F-ON or S4148F-ON) switch, or multiple switches, if stacking
• AC country- and regional-specic cables to connect the AC power source to each of the switches' AC power supplies
• Mounting brackets for rack installation, included
• Screws for rack installation
• #1 and #2 Phillips screwdrivers, not included
• Torx screwdriver, not included
• Ground cable screws, included
• Copper or ber cables
Other optional components are:
• Ground cable and lug for the frame-end of the ground cable
• Extra power supply unit
• Extra fan module
• Extra mounting brackets if installing in a four-post rack or cabinet
S4100–ON Series congurations
The S4100–ON Series (S4128F-ON and S4148F-ON) switches are available in several dierent congurations.
All S4100–ON Series switches include the following congurations:
• Fan with airow from the I/O side to the PSU side—normal
• Fan with airow from the PSU side to the I/O side—reverse
• AC power supply with airow from the I/O side to the PSU side—normal
• AC power supply with airow from the PSU side to the I/O side—reverse
• DC power supply with airow from the I/O side to the PSU side—normal
• DC power supply with airow from the PSU side to the I/O side—reverse
The following table lists each S4100-ON Series switch conguration:
Table 11. S4100–ON Series
congurations
S4100F–ON Series
Switch
Conguration
S4128F-ON AC or
DC Normal airow
28 xed SFP+ ports, 2 xed QSFP28 ports, 7-segment stacking indicator, 1 micro-USB-B
console port, 1 USB type-A port, 1 RJ-45 10/100/1000 Base-T Ethernet management port,
2 AC or DC PSUs, and 4 fan trays.
S4128F-ON AC or
DC Reverse airow
28 xed SFP+ ports, 2 xed QSFP28 ports, 7-segment stacking indicator, 1 micro-USB-B
console port, 1 USB type-A port, 1 RJ-45 10/100/1000 Base-T Ethernet management port,
2 AC or DC PSUs, and 4 fan trays.
S4148F-ON AC or
DC Normal airow
48 xed SFP+ ports, 2 xed QSFP+ ports, 4 xed QSFP28 ports, 7-segment stacking
indicator, 1 micro-USB-B console port, 1 USB type-A port, 1 RJ-45 10/100/1000 Base-T
Ethernet management port, 2 AC or DC PSUs, and 4 fan trays.
S4148F-ON AC or
DC Reverse airow
48 xed SFP+ ports, 2 xed QSFP+ ports, 4 xed QSFP28 ports, 7-segment stacking
indicator, 1 micro-USB-B console port, 1 USB type-A port, 1 RJ-45 10/100/1000 Base-T
Ethernet management port, 2 AC or DC PSUs, and 4 fan trays.
14 S4100–ON Series switch

Dell S4128F-ON Series Specifications

General

Rack Units	1U
Airflow	Front-to-back or back-to-front
Manageable	Yes
Jumbo Frame Support	Yes
Jumbo Frame Size	9216 bytes
Model	S4128F-ON
Switch Type	Layer 3
Form Factor	Rack-mountable
Ports	28 x 10GbE SFP+
Power Supply	2
Product Type	Ethernet Switch
MAC Address Table Size	128000
Input Voltage	100 V AC to 240 V AC
Power Consumption Operational	200 W
Product Series	S-Series
Forwarding Capacity	1.072 Bpps
Operating System	Open Networking (ON)
