NOTE: Before starting this procedure, be sure that you have a terminal emulation program already installed on your PC. Install
the appropriate drivers to support the USB-B port. For assistance, contact www.dell.com/support to download the drivers.
To access the USB-B console port, follow these steps.
1 Power on the PC.
2 Connect the USB-A end of cable into an available USB port on the PC.
3 Connect the USB-B end of cable into the USB-B console port on the S4100-ON Series switch.
4 Power on the S4100-ON Series switch.
5 Install the necessary USB device drivers. (To download the drivers, go to www.dell.com/support.)
For assistance, contact Dell EMC Technical Support.
6 Open your terminal software emulation program to access the S4100-ON Series switch.
7 Conrm that the terminal settings on your terminal software emulation program are as follows:
115200 baud rate
No parity
8 data bits
1 stop bit
No ow control
Before you install an OS
After powering on the S4100–ON Series (S4128F-ON and S4148F-ON) switch, it goes through a power-on self-test (POST).
POST runs every time the switch is initialized and checks the hardware components to determine if the switch is fully operational before
booting. After POST, the switch uses the Grub bootloader.
To select an entry, use the up and down arrow keys. Press Enter to select an operating software (OS) or enter e to edit the commands
before booting. Enter c for a command line. The selected entry runs automatically in the operating system.
Grub bootloader example
GNU GRUB version 2.02~beta2+e4a1fe391
+--------------------------------------------------+
|*ONIE: Install OS |
| ONIE: Rescue |
| ONIE: Uninstall OS |
| ONIE: Update ONIE |
| ONIE: Embed ONIE |
| Diag ONIE |
| |
| |
| |
| |
| |
| |
+--------------------------------------------------+
Your switch comes with ONIE installed.
NOTE
: To access ONIE, use the RJ-45 console port.
ONIE example
ONIE: Install OS
For downloading and installing an OS from a URL
Management ports
37

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell S4128F-ON Series and is the answer not in the manual?

Dell S4128F-ON Series Specifications

General IconGeneral
Rack Units1U
AirflowFront-to-back or back-to-front
ManageableYes
Jumbo Frame SupportYes
Jumbo Frame Size9216 bytes
ModelS4128F-ON
Switch TypeLayer 3
Form FactorRack-mountable
Ports28 x 10GbE SFP+
Power Supply2
Product TypeEthernet Switch
MAC Address Table Size128000
Input Voltage100 V AC to 240 V AC
Power Consumption Operational200 W
Product SeriesS-Series
Forwarding Capacity1.072 Bpps
Operating SystemOpen Networking (ON)
