Table 7. QSFP28 port LEDs: 4x25G or 4x10G mode
LED Description
Link/Activity LED
O—No link
Solid green—Link operating at maximum speed—4x25G port
Flashing green—Link activity operating at maximum speed—
4x25G port
Solid yellow—Link operating at a lower speed—4x10G port
Flashing yellow—Port activity at a lower speed—4x10G port
Flashing yellow, 1 second on/o—Port beacon
Table 8. QSFP28 port LEDs: 2x50G mode
LED Description
Link/Activity LED
O—No link
Solid yellow—Link operating at a lower speed—2x50G port
Flashing yellow—Link activity at a lower speed—2x50G port
Flashing yellow, 1 second on/o—Port beacon
Table 9. QSFP+ port LEDs
LED Description
Link/Activity LED
O—No link
Solid green—Link operating at maximum speed—40G port
Flashing green—Link activity operating at maximum speed—
40G port
Solid yellow—Link operating at a lower speed—40G port
Flashing yellow—Link activity at a lower speed—40G port
Flashing yellow, 1 second on/o—Port beacon
Table 10. QSFP+ port LEDs: 4x10G/1G mode
LED Description
Link/Activity LED—4x10G mode
O—No link
Solid green—Link operating at maximum speed—10G port
Flashing green—Link activity operating at maximum speed—
10G port
Solid yellow—Link operating at a lower speed—1G port
Flashing yellow—Link activity at a lower speed—1G port
Flashing yellow, 1 second on/o—Port beacon
Prerequisites
The following is a list of required and optional components for the S4100–ON Series (S4128F-ON and S4148F-ON) switch:
NOTE
: Detailed installation instructions are provided in the Site preparations and S4100-ON Series installation sections.
S4100–ON Series switch 13

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Dell S4128F-ON Series and is the answer not in the manual?

Dell S4128F-ON Series Specifications

General IconGeneral
Rack Units1U
AirflowFront-to-back or back-to-front
ManageableYes
Jumbo Frame SupportYes
Jumbo Frame Size9216 bytes
ModelS4128F-ON
Switch TypeLayer 3
Form FactorRack-mountable
Ports28 x 10GbE SFP+
Power Supply2
Product TypeEthernet Switch
MAC Address Table Size128000
Input Voltage100 V AC to 240 V AC
Power Consumption Operational200 W
Product SeriesS-Series
Forwarding Capacity1.072 Bpps
Operating SystemOpen Networking (ON)
