2. Gently press down on the display hinges to align the screw holes on the display hinges with the screw holes on the palm-rest
and keyboard assembly.
3. Replace the four (M2.5x5) screws that secure the display hinges to the palm-rest and keyboard assembly.
NOTE: The power-adapter port is secured in place by the left display hinge. There is no screw, tape, or adhesives
securing the power-adapter port to the palm rest. As a result technicians should take note of whether or not the power
adapter port has fallen out of the system during subsequent removal procedures.
4. Connect the display cable to the connector on the system board.
Next steps
1. Install the base cover.
2. Install the SD card.
3. Follow the procedure in After working inside your computer.
Removing the display assembly (Plastic)
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the SSD.
5. Remove the wireless card.
About this task
The following images indicate the location of the display assembly and provide a visual representation of the removal procedure.
