About this task
The following images indicate the location of the camera module (in a system shipped with plastic chassis) and provide a visual
representation of the installation procedure.
Steps
1. Adhere the camera module in its slot on the display assembly.
2. Connect the camera cable to the camera module.
Next steps
1. Install the eDP cable.
2. Install the display panel.
3. Install the display hinges.
4. Install the display bezel.
5. Install the display hinge caps.
6. Install the display assembly.
7. Install the wireless card.
8. Install the base cover.
9. Install the SD card.
10. Follow the procedure in After working inside your computer.
Removing the camera module (Aluminum)
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the SD card.
3. Remove the base cover.
4. Remove the wireless card.
5. Remove the display assembly.
6. Remove the display hinge caps.
7. Remove the display bezel.
8. Remove the display hinges.
9. Remove the display panel.
10. Remove the eDP cable.
