About this task
The following images indicate the location of the memory modules and provide a visual representation of the removal procedure.
Steps
1. Lay the chassis on the right side.
2. Use your fingertips to carefully spread apart the securing-clips on each end of the memory-module slot.
3. Grasp the memory module near the securing clip, and then gently ease the memory module out of the memory-module slot.
NOTE: Repeat step 2 to step 4 to remove any other memory modules installed in your computer.
NOTE: If the memory module is difficult to remove, gently ease the memory module back and forth to remove it from
the slot.
NOTE: To prevent damage to the memory module, hold the memory module by the edges. Do not touch the
components on the memory module.
Installing the memory modules
Prerequisites
About this task
The following images indicate the location of the memory modules and provide a visual representation of the installation procedure.
16
Disassembly and reassembly
