Coin-cell battery
Removing the coin-cell battery
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the right-side cover.
About this task
The following images indicate the location of the coin-cell battery and provide a visual representation of the removal procedure.
Steps
1. Lay the computer on the right side.
2. Using a plastic scribe, push the coin-cell battery-release lever on the coin-cell battery socket to release the coin-cell battery out of the
socket.
3. Remove the coin-cell battery.
Installing the coin-cell battery
Prerequisites
About this task
The following images indicate the location of the coin-cell battery and provide a visual representation of the installation procedure.
28
Disassembly and reassembly
