Dell Vostro 5880 - Installing the Processor Fan and Heat-Sink Assembly

2. Remove the right-side cover.
About this task
The following images indicate the location of the base cover and provide a visual representation of the removal procedure.
Steps
1. Locate the processor fan and heat-sink assembly on your computer.
2. Disconnect the processor-fan cable from the system board.
3. Loosen the captive screws that secure the processor fan and heat-sink assembly to the system board, as per the callout on the
system board.
4. Lift the processor fan and heat-sink assembly off the system board.
Installing the processor fan and heat-sink assembly
Prerequisites
About this task
The following images indicate the location of the base cover and provide a visual representation of the installation procedure.
44
Disassembly and reassembly
