Keyboard 53
15
Keyboard
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the base cover. See "Removing the Base Cover" on page 13
2
Remove the battery. See "Removing the Battery" on page 17
3
Remove the speakers. See "Removing the Speakers" on page 19
4
Remove the Mini-Card. See "Removing the Mini-Card" on page 23
5
Remove the solid-state drive. See "Removing the Solid-State Drive" on
page 27
6
Remove the heat sink. See "Removing the Heat Sink" on page 31
7
Remove the fan. See "Removing the Fan" on page 33
8
Remove the power-adapter connector. See "Removing the Power-Adapter
Connector" on page 37
9
Remove the I/O board. See "Removing the I/O Board" on page 41
10
Remove the system board. See "Removing the System Board" on page 45
Removing the Keyboard
1
Remove the screw that secures the Mini-Card clamp.
2
Remove the Mini-Card clamp off the palm-rest assembly.
Spyder_OM_Book.book Page 53 Monday, January 16, 2012 11:02 AM
