Display Assembly 57
16
Display Assembly
WARNING: Before working inside your computer, read the safety information
that shipped with your computer and follow the steps in "Before You Begin" on
page 9. For additional safety best practices information, see the Regulatory
Compliance Homepage at dell.com/regulatory_compliance.
Prerequisites
1
Remove the base cover. See "Removing the Base Cover" on page 13
2
Remove the battery. See "Removing the Battery" on page 17
3
Remove the speakers. See "Removing the Speakers" on page 19
4
Remove the power-adapter connector. See "Removing the Power-Adapter
Connector" on page 37
Removing the Display Assembly
1
Disconnect the display cable from the system-board connector.
Spyder_OM_Book.book Page 57 Monday, January 16, 2012 11:02 AM
