Delta AH Series Hardware Manual

Chapter 4 Installation and Wiring
4-5
4
_
- Analog input/output modules:
AH04AD-5A
Four-channel analog input module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, 0/4~20 mA, or -20~+20 mA
AH08AD-5A
Eight-channel analog input module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, 0/4~20 mA, or -20~+20 mA
AH08AD-5B
Eight-channel analog input module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V
AH08AD-5C
Eight-channel analog input module
16-bit resolution
0/4~20 mA or -20~+20 mA
AH04DA-5A
Four-channel analog output module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, or 0/4~20 mA
AH08DA-5A
Eight-channel analog output module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, or 0/4~20 mA
AH08DA-5B
Eight-channel analog output module
16-bit resolution
-10~+10 V, 0~10 V, -5~+5 V, or 0/1~5 V
AH08DA-5C
Eight-channel analog output module
16-bit resolution
0/4~20 mA
AH06XA-5A
Four-channel analog input and two-channel analog output module
16-bit resolution
Analog input: -10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, 0/4~20 mA, or -20~+20 mA
Analog output: -10~+10 V, 0~10 V, -5~+5 V, 0/1~5 V, or 0/4~20 mA
- Temperature measurement modules:
AH04PT-5A
Four-channel four-wire/three-wire RTD
Sensor type: Pt100, Pt1000, Ni100, Ni1000, or 0~300 Ω input impedance
AH08PTG-5A
Eight-channel four-wire/three-wire/two-wire RTD
Sensor type: Pt100, Pt1000, Ni100, Ni1000, or 0~300 Ω input impedance
AH04TC-5A
Four-channel thermocouple
Sensor type: J, K, R, S, T, E, N, or -150~+150 mV
AH08TC-5A
Eight-channel thermocouple
Sensor type: J, K, R, S, T, E, N, or -150~+150 mV
- Network modules:
AH10EN-5A
It is an Ethernet communication module with two Ethernet ports, and supports Modbus
TCP protocols, and EtherNet/IP software (V2.0). It can function as a master or a slave.
AH15EN-5A
It is an Ethernet communication module with two Ethernet ports, and supports Modbus
TCP protocols, and IEC60870-5-104. It can function as a master or a slave.
AH10SCM-5A It is a serial communication module with two RS-485/RS-422 ports, and supports
