Delta ASDA-M Series User Manual

Chapter 11 Specifications ASDA-M
11-8 Revision December, 2014
Medium-high/ High inertia series
ECMA
F△13
08
Rated power (kW)
0.85
Rated torque (N-m)
*1
5.41
Max. torque (N-m)
13.8
Rated speed (r/min)
1500
Max. speed (r/min)
3000
Rated current (A)
7.1
Max. instantaneous current (A)
19.4
Max. power per second (kW/s)
21.52
Rotor inertia (× 10
-4
kg.m
2
)
13.6
Mechanical constant (ms)
2.43
Torque constant – KT(N-m/A)
0.76
Voltage constant – KE
(mV/(r/min))
29.2
Armature resistance (Ohm)
0.38
Armature inductance (mH)
4.77
Electric constant (ms)
12.55
Insulation class
Class A (UL), Class B (CE)
Insulation resistance
＞100M，DC 500V
Insulation strength
1.8k Vac,1 sec
Weight – without brake (kg)
8.6
Weight – with brake (kg)
10.0
Radial max. loading (N)
490
Axial max. loading (N)
98
Max. power per second (kW/s)
(with brake)
19.78
Rotor inertia (× 10
-4
kg.m
2
)
(with brake)
14.8
