ASDA-M Chapter 11 Specifications
Revision December, 2014
11-9
Note
*1 The rated torque is the continuous permissible torque between 0~40˚C operating temperature which is
suitable for the following heat sink dimension.
ECMA-_ _ 04 / 06 / 08250mm x 250mm x 6mm
ECMA-_ _ 10300mm x 300mm x 12mm
ECMA-_ _ 13400mm x 400mm x 20mm
Material: Aluminum– F40, F60, F80, F100, F130
*2 The built-in brake of the servo motor is for remaining the item in stop status. Do not use it to decelerate or
as the dynamic brake.
3 If desire to reach the max. torque limit for motor 250%, it suggested to use the servo drive with higher
watt.
ECMA
F13
08
Mechanical constant (ms)
(with brake)
2.65
Brake holding torque
[Nt-m (min)]
*2
10.0
Brake power consumption
(at 20˚C) [W]
19.0
Brake release time [ms (Max)]
10
Brake pull-in time [ms (Max)]
70
Vibration grade (μm)
15
Operating temperature (˚C)
0 ~ 40
Storage temperature (˚C)
-10 ~ 80
Operating humidity
20 ~ 90% RH (non-condensing)
Storage humidity
20 ~ 90% RH (non-condensing)
Vibration capacity
2.5 G
IP Rating
IP65 (use the waterproof connector and shaft
seal installation (or oil seal) model)
Approvals
