Chapter 11 Specifications ASDA-M
11-20 Revision December, 2014
Motor Frame Size: 100 ~ 130 (Units: mm)
Model
F1308 S G1303 S G1306 S G1309 S
LC 130 130 130 130
LZ 9 9 9 9
LA 145 145 145 145
S
)
(
.
22
0
0130
)
(
.
22
0
0130
)
(
.
22
0
0130
)
(
.
22
0
0130
LB
)
(
.
110
0
0350
)
(
.
110
0
0350
)
(
.
110
0
0350
)
(
.
110
0
0350
LL
without brake
152.5 147.5 147.5 163.5
LL
with brake
181 183.5 183.5 198
LS 47 47 47 47
LR 55 55 55 55
LE 6 6 6 6
LG 11.5 11.5 11.5 11.5
LW 36 36 36 36
RH 18 18 18 18
WK 8 8 8 8
W 8 8 8 8
T 7 7 7 7
TP
M6
Depth 20
M6
Depth 20
M6
Depth 20
M6
Depth 20
NOTE
1) Dimensions are in millimeters.
2) Dimensions and weights might be revised without prior notice.
3) Box, () represents the shaft end/ brake or the number of oil seal.
4) Triangle, () represents the type of encoder. Please refer to Chapter 1 for
detail
