Delta DVP-PLC User Manual

7 Application Instructions API 50-99
DVP-PLC APPLICATION MANUAL
7-29
3. Flags and special registers for EH/EH2/SV series MPU:
M1010: (EH/EH2/SV) When On, CH0, CH1, CH2 and CH3 will output pulses at END instruction. Off when
the output starts.
M1029: (EH/EH2/SV) On when CH0 pulse output is completed.
M1030: (EH/EH2/SV) On when CH1 pulse output is completed.
M1036: (EH2/SV) On when CH2 pulse output is completed.
M1037: (EH2/SV) On when CH3 pulse output is completed.
M1334: (EH/EH2/SV) CH0 pulse output pauses.
M1335: (EH/EH2/SV) CH1 pulse output pauses.
M1520: (EH2/SV) CH2 pulse output pauses.
M1521: (EH2/SV) CH3 pulse output pauses.
M1336: (EH/EH2/SV) CH0 pulse output has been sent.
M1337: (EH/EH2/SV) CH1 pulse output has been sent.
M1522: (EH2/SV) CH2 pulse output has been sent.
M1523: (EH2/SV) CH3 pulse output has been sent.
M1338: (EH/EH2/SV) CH0 offset pulses enabled.
M1339: (EH/EH2/SV) CH1 offset pulses enabled.
M1340: (EH/EH2/SV) I110 interruption occurs after CH0 pulse output is completed.
M1341: (EH/EH2/SV) I120 interruption after occurs CH1 pulse output is completed.
M1342: (EH/EH2/SV) I130 interruption occurs when CH0 pulse output is sending.
M1343: (EH/EH2/SV) I140 interruption occurs when CH0 pulse output is sending.
M1344: (EH/EH2/SV) CH0 pulse compensation enabled.
M1345: (EH/EH2/SV) CH1 pulse compensation enabled.
M1347: (EH/EH2/SV) CH0 pulse output reset flag
M1348: (EH/EH2/SV) CH1 pulse output reset flag
M1524: (EH2/SV) CH2 pulse output reset flag
M1525: (EH2/SV) CH3 pulse output reset flag
D1220: (EH/EH2/SV) Phase setting of CH0 (Y0, Y1): D1220 determines the phase by the last two bits;
other bits are invalid.
1. K0: Y0 output
2. K1: Y0, Y1 AB-phase output; A ahead of B.
3. K2: Y0, Y1 AB-phase output; B ahead of A.
4. K3: Y1 output
D1221: (EH/EH2/SV) Phase setting of CH1 (Y2, Y3): D1221 determines the phase by the last two bits;
other bits are invalid.
1. K0: Y2 output
2. K1: Y2, Y3 AB-phase output; A ahead of B.
3. K2: Y2, Y3 AB-phase output; B ahead of A.
4. K3: Y3 output
