Delta DVP-PLC User Manual

9 Application Instructions API 150-199
DVP-PLC Application Manual
9-4
10. RTU Mode: When PLC is connected to VFD-S AC motor drive
PLC Ö VFD-S, PLC sends: “01 03 2100 0006 CF F4”
VFD-S Ö PLC, PLC receives: “01 03 0C 0000 0503 0BB8 0BB8 0000 012D 8E C5”
Registers for sent data (sending messages)
Register DATA Explanation
D1256 Low 01 H Address
D1257 Low 03 H Function
D1258 Low 21 H
D1259 Low 00 H
Starting Data Address
D1260 Low 00 H
D1261 Low 06 H
Number of Data (counted by words)
D1262 Low CF H CRC CHK Low
D1263 Low F4 H CRC CHK High
Registers for received data D0 (responding messages)
Register DATA Explanation
D0 Low 01 H Address
D1 Low 03 H Function
D2 Low 0C H Number of Data (byte)
D3 Low 00 H
D4 Low 00 H
Content of
address 2100H
PLC automatically convert ASCII codes to numerals and
store the numeral in D1296 = H0000
D5 Low 05 H
D6 Low 03 H
Content of
address 2101H
PLC automatically convert ASCII codes to numerals
and store the numeral in D1297 = H0503
D7 Low 0B H
D8 Low B8 H
Content of
address 2102H
PLC automatically convert ASCII codes to numerals
and store the numeral in D1298 = H0BB8
D9 Low 0B H
D10 Low B8 H
Content of
address 2103H
PLC automatically convert ASCII codes to numerals
and store the numeral in D1299 = H0BB8
D11 Low 00 H
D12 Low 00 H
Content of
address 2104H
PLC automatically convert ASCII codes to numerals
and store the numeral in D1300 = H0000
D13 Low 01 H
D14 Low 2D H
Content of
address 2105H
PLC automatically convert ASCII codes to numerals
and store the numeral in D1301 = H012D
D15 Low 8E H CRC CHK Low
D16 Low C5 H CRC CHK High
Program Example 2:
1. Function code K6(H6): For writing a word data to register
When PLC is connected to VFD-S AC motor drive: M1143 = Off, in ASCII mode
When PLC is connected to VFD-S AC motor drive: M1143 = On, in RTU mode
2. When in ASCII mode, the user stores the data to be written in the designated register D50 in hex format. The
data sent back from AC motor drive are stored in D1070 ~ D1076.
3. When in RTU mode, the user stores the data to be written in the designated register D50 in hex format. The
data sent back from AC motor drive are stored in D1070 ~ D1077.
4. When In ASCII mode or RTU mode, PLC will store the data to be sent in D1256 ~ D1295. If necessary, the
user can move the data to other general registers by using MOV, DMOV or BMOV instruction. Other
instructions of ES/EX/SS do not function on the data in D1256 ~ D1295.

Delta DVP-PLC Specifications

General

Manufacturer	Delta Electronics
Model	DVP-PLC
Category	Controller
Humidity	5% to 95% RH, non-condensing
Programming Language	Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC)
CPU Type	Various, depending on the specific model within the DVP series (e.g., ES2, EX2, SX2, SA2, EH3, etc.)
Operating Temperature	Typically 0°C to 55°C (32°F to 131°F)
Storage Temperature	Typically -25°C to 70°C (-13°F to 158°F)
