Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-35
Special
M
Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STO
P
Attribute Latched Default
M1030*
ES/SA: Y1 pulse output of PLSY, PLSR instructions
is completed, or other relevant instructions complete
their executions.
EH/EH2/SV: the 2
nd
group pulse output CH1 (Y2,
Y3) is completed, or other relevant instructions
complete their executions.
○ ○ ○
Off - - R NO Off
M1031* Clear all non-latched areas
○ ○ ○
Off - - R/W NO Off
M1032* Clear all latched areas
○ ○ ○
Off - - R/W NO Off
M1033* Memory latched when STOP
○ ○ ○
Off - - R/W NO Off
M1034* Disabling all Y outputs
○ ○ ○
Off - - R/W NO Off
M1035*
Enabling input point X as the RUN/STOP switch,
corresponding to D1035
(SA designates X7 only; SX designates X3 only; SC
designates X5 only)
╳
○ ○
- - - R/W YES Off
EH2/SV: the 3
rd
group pulse output CH2 (Y4, Y5) is
completed. (Not available in EH)
╳ ╳
○
Off - - R NO Off
M1036
SPD instruction is able to use X0 ~ X5 to detect the
flag (only available in SC_V1.4 and above)
╳
○
╳
Off Off - R/W NO Off
M1037
EH2/SV: the 4
th
group pulse output CH3 (Y6, Y7) is
completed. (Not available in EH)
╳ ╳
○
Off - - R NO Off
M1039* Fixing time scan mode
○ ○ ○
Off - - R/W NO Off
M1040 Disabling step
○ ○ ○
Off - - R/W NO Off
M1041 Starting step
○ ○ ○
Off - Off R/W NO Off
M1042 Enabling pulses
○ ○ ○
Off - - R/W NO Off
M1043 Zero return completed
○ ○ ○
Off - Off R/W NO Off
M1044 Zero point condition
○ ○ ○
Off - Off R/W NO Off
M1045 Diabling all output reset
○ ○ ○
Off - - R/W NO Off
M1046 Setting STL status as On
○ ○ ○
Off - - R NO Off
M1047 Enabling STL monitoring
╳
○ ○
Off - - R/W NO Off
M1048 Alarm status
╳
○ ○
Off - - R NO Off
M1049 Setting up alarm monitoring
╳
○ ○
Off - - R/W NO Off
M1050 Inhibiting I001
○ ○
╳
Off - - R/W NO Off
M1051 Inhibiting I101
○ ○
╳
Off - - R/W NO Off
M1052 Inhibiting I201
○ ○
╳
Off - - R/W NO Off
M1053 Inhibiting I301
○ ○
╳
Off - - R/W NO Off
M1054 Inhibiting I401
╳
○
╳
Off - - R/W NO Off
M1055 Inhibiting I501
╳
○
╳
Off - - R/W NO Off

Delta DVP-PLC Specifications

General

Manufacturer	Delta Electronics
Model	DVP-PLC
Category	Controller
Humidity	5% to 95% RH, non-condensing
Programming Language	Ladder Diagram (LD), Instruction List (IL), Sequential Function Chart (SFC)
CPU Type	Various, depending on the specific model within the DVP series (e.g., ES2, EX2, SX2, SA2, EH3, etc.)
Operating Temperature	Typically 0°C to 55°C (32°F to 131°F)
Storage Temperature	Typically -25°C to 70°C (-13°F to 158°F)
