Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-38
Special
M
Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STO
P
Attribute Latched Default
M1109* Status of SW6 on digital switch card
╳ ╳
○
Off Off - R NO Off
M1110* Status of SW7 on digital switch card
╳ ╳
○
Off Off - R NO Off
M1111* Status of SW8 on digital switch card
╳ ╳
○
Off Off - R NO Off
M1112* AY0 output point on 2DO card (transistor)
╳ ╳
○
Off - Off R/W NO Off
M1113* AY1 output point on 2DO card (transistor)
╳ ╳
○
Off - Off R/W NO Off
M1115*
Switch for enabling pulse accelerating/decelerating
output (not available in SC_V1.4 and above)
○ ○
╳
Off Off Off R/W NO Off
M1116*
Pulse output is accelerating (not available in
SC_V1.4 and above)
○ ○
╳
Off Off Off R/W NO Off
M1117*
Accelerating/decelerating pulse output reaches its
target (not available in SC_V1.4 and above)
○ ○
╳
Off Off Off R/W NO Off
M1118*
Pulse output is decelerating (not available in
SC_V1.4 and above)
○ ○
╳
Off Off Off R/W NO Off
M1119*
Accelerating/decelerating pulse output is completed
(not available in SC_V1.4 and above)
○ ○
╳
Off Off Off R/W NO Off
M1120*
Retaining the communication setting of COM2
(RS-485), modifying D1120 will be invalid when
M1120 is set.
○ ○ ○
Off Off - R/W NO Off
M1121
Waiting for the sending of RS-485 communication
data
○ ○ ○
Off On - R NO Off
M1122 Sending request
○ ○ ○
Off Off - R/W NO Off
M1123 Receiving is completed
○ ○ ○
Off Off - R/W NO Off
M1124 Waiting for receiving
○ ○ ○
Off Off - R NO Off
M1125 Communication reset
○ ○ ○
Off Off - R/W NO Off
M1126 Selecting STX/ETX user defined or system defined
○ ○ ○
Off Off - R/W NO Off
M1127
Sending/receiving data of communication instruction
is completed (RS instruction not included)
○ ○ ○
Off Off - R/W NO Off
M1128 Sending…/receiving... indication
○ ○ ○
Off Off - R NO Off
M1129 Receiving time-out
○ ○ ○
Off Off - R/W NO Off
M1130 Selectin STX/ETX user defined or system defined
○ ○ ○
Off Off - R/W NO Off
M1131
On during MODRD/RDST/MODRW data are
converted to hex data
○ ○ ○
Off Off - R NO Off
M1132
On when there are no communication related
instructions in the program
○ ○ ○
Off - - R NO On
M1133*
Enabling special high-speed pulse output Y0
(50KHz)
SC_V1.4 and above: 2-axis synchronous control,
enabling Y10 output
╳
○
╳
Off Off Off R/W NO Off
