2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-56
Special D Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STOP
Attribute Latched Default
D1127
Interruption request for receiving specific word in RS
instruction (I150)
○
╳ ╳
0 - - R/W NO 0
D1129 Abnormal communication time-out (time: ms)
○ ○ ○
0 - - R/W NO 0
D1130 Error code returning from Modbus
○ ○ ○
0 - - R NO 0
D1133*
SA/SX: start No. of register D for Y0 special
high-speed pulse output (50KHz)
SC_V1.4 and above: start No. of register D for Y10
2-axis synchronous control output
╳
○
╳
0 - - R/W NO 0
D1134*
Number of sections in Y10 output for 2-axis
synchronous control (available in SC_V1.4 and
above)
╳
○
╳
0 - - R/W NO 0
D1135*
SC_V1.4 and above: start No. of register D for Y11
2-axis synchronous control output
╳
○
╳
0 - - R/W NO 0
D1136*
Number of sections in Y11 output for 2-axis
synchronous control (available in SC_V1.4 and
above)
╳
○
╳
0 - - R/W NO 0
D1137* Address where incorrect use of operand occurs
○ ○ ○
0 0 - R NO 0
D1140*
Number of right-side special extension modules
(max. 8)
○ ○ ○
0 - - R NO 0
D1142* Number of points X in digital extension unit
○ ○ ○
0 - - R NO 0
D1143* Number of points Y in digital extension unit
○ ○ ○
0 - - R NO 0
D1144*
Start No. of register D for Y0 adjustable
acceleration/deceleration pulse output
╳
○
╳
0 - - R/W NO 0
D1145*
Number of left-side special extension modules (max.
8) (only available in SV)
╳ ╳
○
0 - - R NO 0
D1147
Type of memory card
b0 = 0: no card existing (H0000)
b0 = 1: with flash card
b8 = 0: flash card Off (H0001)
b8 = 1: flash card On (H0101)
╳ ╳
○
0 - - R NO 0
D1149
Type of function extension card
0: no card
1: RS-232 card, DU-01
2: RS-422 card
3: COM3 card
4: analog rotary switch card
5: digital switch card
6: transistor output card
8: 2AD card
9: 2DA card
10: frequency measurement card
╳ ╳
○
0 - - R NO 0
