Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-57
Special D Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STOP
Attribute Latched Default
D1150
Table count register in multi-group setting
comparison mode of DHSZ commnad
╳ ╳
○
0 0 0 R NO 0
D1151
Table counting register for DHSZ multiple set values
comparison mode
╳ ╳
○
0 0 0 R NO 0
D1152 High word of changed D value for DHSZ instruciton
╳ ╳
○
0 0 0 R NO 0
D1153 Low word of changed D value for DHSZ instruction
╳ ╳
○
0 0 0 R NO 0
D1154*
Suggested deceleration time interval (10 ~
32,767ms) for adjustable acceleration/deceleration
pulse output Y0
╳
○
╳
200 - - R/W NO 200
D1155*
Suggested deceleration frequency (-1 ~ -32,700Hz)
for adjustable acceleration/deceleration pulse output
Y0
╳
○
╳
-1,000
- - R/W NO -1,000
D1156
↓
D1165
Designated special D for RTMU, RTMD instructions
╳ ╳
○
0 - - R/W NO 0
D1166*
Switching rising-/falling-edge counting mode of X10
(available in SC_V1.4 and above)
╳
○
╳
0 - - R/W NO 0
D1167*
Switching rising-/falling-edge counting mode of X11
(available in SC_V1.4 and above)
╳
○
╳
0 - - R/W NO 0
D1168
Interruption request for receiving specific word in RS
instruction (I150)
╳
○ ○
0 - - R/W NO 0
D1169
Interruption request for receiving specific word in RS
instruction (I160)
╳ ╳
○
0 - - R/W NO 0
D1170* PC value when executing single step
╳ ╳
○
0 0 0 R NO 0
D1172* Frequency of 2-phase pulse output (12Hz ~ 20KHz)
╳
○
╳
0 - - R/W NO 0
D1173* Modes of 2-phase pulse output (K1 and K2)
╳
○
╳
0 - - R/W NO 0
D1174*
Low 16 bits of target numbers of 2-phase output
pulses
╳
○
╳
0 - - R/W NO 0
D1175*
High 16 bits of target numbers of 2-phase output
pulses
╳
○
╳
0 - - R/W NO 0
D1176*
Low 16 bits of current numbers of 2-phase output
pulses
╳
○
╳
0 - - R/W NO 0
D1177*
High 16 bits of current numbers of 2-phase output
pulses
╳
○
╳
0 - - R/W NO 0
D1178* VR0 value
╳
○ ○
0 - - R NO 0
D1179* VR1 value
╳
○ ○
0 - - R NO 0
D1180*
Low 16 bytes of high-speed counter value extracted
by interruption I401
╳
○
╳
0 - - R NO 0
D1181*
High 16 bytes of high-speed counter value extracted
by interruption I401
╳
○
╳
0 - - R NO 0
D1182 Index register E1
╳
○ ○
0 - - R/W NO 0
