Delta DVP-PLC User Manual

2 Functions of Devices in DVP-PLC
DVP-PLC Application Manual
2-58
Special D Function
ES
EX
SS
SA
SX
SC
EH
EH2
SV
Off
Ø
On
STOP
Ø
RUN
RUN
Ø
STOP
Attribute Latched Default
D1183 Index register F1
╳
○ ○
0 - - R/W NO 0
D1184 Index register E2
╳
○ ○
0 - - R/W NO 0
D1185 Index register F2
╳
○ ○
0 - - R/W NO 0
D1186 Index register E3
╳
○ ○
0 - - R/W NO 0
D1187 Index register F3
╳
○ ○
0 - - R/W NO 0
D1188 Index register E4
╳ ╳
○
0 - - R/W NO 0
D1189 Index register F4
╳ ╳
○
0 - - R/W NO 0
D1190 Index register E5
╳ ╳
○
0 - - R/W NO 0
D1191 Index register F5
╳ ╳
○
0 - - R/W NO 0
D1192 Index register E6
╳ ╳
○
0 - - R/W NO 0
D1193 Index register F6
╳ ╳
○
0 - - R/W NO 0
D1194 Index register E7
╳ ╳
○
0 - - R/W NO 0
D1195 Index register F7
╳ ╳
○
0 - - R/W NO 0
D1196 Content in the display (available in SX)
╳
○
╳
0 - - R/W NO 0
D1198*
Low 16 bytes of high-speed counter value extracted
by interruption I501
╳
○
╳
0 - - R NO 0
D1199*
Low 16 bytes of high-speed counter value extracted
by interruption I501
╳
○
╳
0 - - R NO 0
D1200*
Start latched address for auxiliary relays M0 ~ M999
# -> EH: 500; SA/SX/SC: 512
╳
○ ○
- - - R/W YES #
D1201* End latched address for auxiliary relays M0 ~ M999
╳
○ ○
- - - R/W YES 999
D1202*
Start latched address for auxiliary relays M2000 ~
M4095
╳
○ ○
- - - R/W YES 2,000
D1203*
End latched address for auxiliary relays M2000 ~
M4095
╳
○ ○
- - - R/W YES 4,095
D1204* Start latched address for 100ms timers T0 ~ T199
╳ ╳
○
- - - R/W YES H'FFFF
D1205* End latched address for 100ms timers T0 ~ T199
╳ ╳
○
- - - R/W YES H’FFFF
D1206* Start latched address for 10ms timers T200 ~ T239
╳ ╳
○
- - - R/W YES H’FFFF
D1207* End latched address for 10ms timers T200 ~ T239
╳ ╳
○
- - - R/W YES H’FFFF
D1208*
Start latched address for16-bit counters C0 ~ C199
# -> EH: 100; SA/SX/SC: 96
╳
○ ○
- - - R/W YES #
D1209* End latched address for 16-bit counters C0 ~ C199
╳
○ ○
- - - R/W YES 199
D1210*
Start latched address for 32-bit counters C200 ~
C234
# -> EH: 220; SA/SX/SC: 216
╳
○ ○
- - - R/W YES #
D1211*
End latched address for 32-bit counters C200 ~
C234
╳
○ ○
- - - R/W YES 234
