3 Functions of Devices in DVP-PM
DVP-PM Application Manual
3-68
2. Attribute of target position P(II):
♦ Absolute coordinate: b12 of D1816 (D1896, D1976, D2056) = 0
Absolute coordinate is the coordinate starting from “0.” When the target position P(II) > current position
(D1848, D1928, D2008, D2088), the motor will conduct forward running. When the target position P(II) <
current position, the motor will conduct reverse running.
♦ Relative coordinate: b12 of D1816 (D1896, D1976, D2056) = 1
Relative coordinate is the relative displacement moved from current position (D1848, D1928, D2008,
D2088). When the relative coordinate is a positive value, the motor will conduct forward running. When the
relative coordinate is a negative value, the motor will conduct reverse running..
3. The multiplication of position data P(II) varies according to the settings of b2 and b3 in D1816 (D1896, D1976,
D2056).
X axis Y axis Z axis A axis
HW LW HW LW HW LW HW LW
D1845 D1844 D1925 D1924 D2005 D2004 D2085 D2084
Operation Speed (II) (V(II))
1. Range: 0 ~ +2,147,483,647; the unit is set by b0 and b1 of D1816 (D1896, D1976, D2056).
2. V(I) should be specified within the valid speed range of motion instructions: 10 ~ 500kPPS. If the value is bigger
than 500k, the output will be set as 500k; if the value is smaller than 10, the output will be set as 10.
3. Setup range limitation: V
MAX
> V(II) > V
BIAS
.
X axis Y axis Z axis A axis
HW LW HW LW HW LW HW LW
D1846 D1926 D2006 D2086
Operation Commands
1. b0 of D1846 (D1926, D2006, D2086): STOP
♦ When b0 is rising edge triggered (0→1), the positioning controller decelerate to stop.
♦ The function is the same as the external STOP input signal. The positioning controller will decelerate to stop
in both situations..
2. b1 of D1846 (D1926, D2006, D2086): START
♦ When b1 is rising edge triggered (0→1), the positioning controller will operates according to operation
conmmands set in D1846 (D1926, D2006, D2086).
3. b2 of D1846 (D1926, D2006, D2086): enabling JOG+
♦ b[2] = 1: JOG+ sends out forward pulses (CW)
♦ When PWM mode is enabled (Parameter Setting, D1816/D1896/D1976/D2056, b[6] = 1), and the operation
command “JOG+ operation” is enabled (b[2] = 1), PWM will be executed on Y0~Y3.
4. b3 of D1846 (D1926, D2006, D2086): enabling JOG-
♦ b[3] = 1: JOG- sends out reverse pulses (CCW)
5. b4 of D1846 (D1926, D2006, D2086): variable speed operation
♦ When b[4] = 1 and operation is started (START terminal is ON), DVP-PM will start to send out pulses for
performing variable speed operation on positioning controller.
♦ The operation speed will be stable after the speed is accelerated from
V
BIAS
to the expected V(I). When
