5 Categories and Use of Basic Application Instructions
DVP-PM Operation Instruction
5-26
API Mnemonic Operands Function
13
SMOV P
Shift Move
Controllers
20PM 10PM
Bit Devices Word devices Program Steps
Type
OP
X Y M S K H KnX KnY KnM KnS T C D E F
S * * * * * * ***
m
1
* *
m
2
* *
D * * * * * ***
n * *
SMOV, SMOVP: 11 steps
Operands:
S: Source device m
1
: Start digit to be moved from source device m
2
: Number of digits to be moved D:
Destination device n: Start digit of the destination device for the moved digits
Explanation:
1. This instruction is able to re-allocate or combine data.
When the instruction is executed, m
2
digits of contents
starting from digit m
1
(from high digit to low digit) of S will be sent to m
2
digits starting from digit n (from high
digit to low digit) of D
2. When SMOV is used as 16-bit instruction, Z device cannot be adopted; when SMOV is used as 32-bit
instruction, V device cannot be adopted.
3. When specifying the bit device of KnX(Y/M/S), the starting No. should be a multiple of 16 in octal or decimal
format. For example, K1X0, K4Y20 (octal); K1M0, K4S16 (decimal).
4. M1168 is used for designating SMOV working mode. When M1168 = ON, the instruction is in BIN mode. When
M1168 = OFF, the instruction is in BCD mode.
Points to note:
1. The range of m
1
: 1 – 4
2. The range of m
2
: 1 – m
1
3. The range of n: m
2
– 4
Program example 1:
1. When M1168 = OFF (in BCD mode) and X0 = ON, the 4
th
(thousand) and 3
rd
(hundred) digit of the decimal
value in D10 start to move to the 3
rd
(hundred) and 2
nd
(ten) digit of the decimal value in D20. 10
3
and 10
0
of
D20 remain unchanged after this instruction is executed.
2. When the BCD value exceeds the range of 0 ~ 9,999, PLC detects an operation error and will not execute the
instruction. M1067, M1068 = ON and D1067 stores the error code OE18 (hex).
