Delta DVP-PM Series User Manual

2 Hardware Specifications and Wiring
DVP-PM Application Manual
2-4
 DVP20PM
24V DC single-ended common point input
Item
Spec
Low speed High speed (200kHz)
#1
Note
Input wiring type Change wiring from S/S to SINK or SOURCE
Input indicator LED display; light on = ON, light off = OFF
Input voltage -
OFFON 20us
Active level
ONOFF 30us
Response time / noise
immunity
#2
10ms 0.5us
#1: Input point A, B and PG are
high-speed inputs; others are
low-speed input.
For 10PM, X0 ~ X7 and X10+ ~
X13+ can be used as general
high-speed input points.
#2: Input point X0 ~ X7 can
conduct 10 ~ 60ms digital filter
adjustment.
 DVP10PM
Double-ended differential
input
24V DC single-ended
common point input
Item
Spec
High speed (200kHz)
Note
Input wiring type Independent wiring
Change wiring from S/S to
SINK or SOURCE
Input indicator LED display; light on = ON, light off = OFF
Input voltage 5~24 VDC 24 VDC
Input current 15mA
OFFON 20us
Active level
ONOFF 30us
Response time / noise
immunity
#1
10ms / 0.5us
#1: Input points support 10 ~
60ms digital filter adjustment,
and 20~85KHz high-frequency
digital filter adjustment.
Digital output points:
 DVP-20PM
Single-ended common point transistor
output
#1
Item
Spec
Low speed High speed
Single-ended common point
#1
relay output
Maximum frequency 10kHz 200kHz For ON/OFF control of load
Output indicator LED display; light on = ON, light off = OFF
Minimum load - 2mA/DC power supply
Working voltage 5 ~ 30VDC < 250V AC, 30VDC
Isolation Photocoupler isolation Electromagnetic isolation
Resistive 0.5A/1 point (2A/COM) 2A/1 point (5A/COM)
Inductive 9W (24V DC)
#2
Current spec.
Lamp 2W (24V DC) 20W DC/100W AC
Max. output
OFFON 20us 0.2us 10ms
