Delta DX-2300 Series User Manual

Chapter 3 Introduction to Functions
3-15
_3
Description Default
Network Services
Select the common network services. Refer to the following common service list for
optional values.
Customized
Service Name
Set up the service name for port forwarding. The name is composed of letters,
numbers and underline, starting with a letter or number. The maximum string length
is 32 bytes.
N/A
Protocol
Set up the protocol type for port forwarding.
TCP/UDP
Public Port
Set up the public port for port forwarding. The port range is 1~65534. A Public port
should be less than or equal to the server port.
Single Port
Server Port
Set up the server port for port forwarding. The port range is 1~65534. A server port
should be greater than or equal to the public port.
When the public port is set to a Single Port, the server port can only be set to a Single
Port. When the public port is set to a Port Range, the server port can be set to a
Single Port or a Port Range. And when the public port is set to a single port, all the
port will be forwarded to ONE single port.
Examples of different port forwarding settings:
1:1
Single Port
