Delta DX-2300 Series User Manual

Chapter 3 Introduction to Functions
3-31
_3
Description Default
Length (1-123)
Here displays the number of the continuous
address followed by the default mapped address.
N/A
Operation
Delete the selected mapped address. N/A
Add Mappings
Click the button to add mappings; the data
mapping can be set to 200.
N/A
Edit
Click to select the records from the mapped address
to edit.
N/A
Operation
The added mappings can be deleted here.
N/A
3.4.6 Log Settings
This page is used for configuring the log settings, including Log to Console, Remote Log Service, Remote Log Server
Address, and Port of Remote Log Server.
Description Default
Log to Console
Set up the log to the console port. No
Remote Log Service
Enable/disable the remote log service. Disable
Port of Remote Log Server
Set up the remote log server port, ranging from 1 to 65534. 514

Delta DX-2300 Series Specifications

General

Brand	Delta
Model	DX-2300 Series
Category	Network Router
Language	English
