Delta DX-2300 Series User Manual

Chapter 4 Introduction to DIACom
4-9
4_
4.2.2 Create a Virtual Serial-port
To debug a remote serial device, click the icon at the back of the corresponding remote
device to enter the Create Virtual Serial Interface
The latest device firmware (V1.3.3) supports RS-232 and RS-485 at the same time in the
transparent mode, the interface as shown below:
Notice
 If the device's RS-232 / RS-485 is not operating in Transparent mode, the
corresponding button is grayed out.
 DIACom will prompt an error message if the FW version of DX is under V1.3.3.
