DX-2300 Series Industrial Ethernet Cloud Router

3-28

Description Default

Add Mappings

Click the button to add mappings; the data mapping

can be set to 200.

N/A

Edit

Click an item of register mapping forms that can be

edited.

Operation

The added mappings can be deleted here. N/A

3.4.5 Modbus TCP

This page is used for configuring the Modbus TCP, including Working Mode, Server IP, Server Port, and Response

Timeout.
