Delta DX-2300 Series User Manual

DX-2300 Series Industrial Ethernet Cloud Router
3-30
_3
Description Default
Add Mappings
Read/Write
Set up the access permissions for the mapped
register address;
 Read-only: The device regular read data from
appointed registers in the slave, but will not
update the data to the slave
 Write-only: The device update the data to the
slave when the registers values was
changed, but will not read the data from the
slave
 Read/write: The device regular read data
from appointed registers in the slave, will
update the data to the slave when the
registers values is changed.
Read/Write
Slave ID
Set up the corresponding slave communication
port. The value is between 1 and 247.
N/A
Controller
Device types:
 Delta PLC: Use this option for Delta DVP / AH
/ AS series PLCs
 Other: Use this option for non-Delta DVP / AH
/ AS series PLCs.
Delta DVP PLC
Address Type
Depending on the selected controller type change:
 Delta PLC: The address type is "D"
 Other: The address type is "W"
D
Slave Starting Address
Set up the slave starting address for read/write the
registers in a PLC.
 Delta PLC: Enter the internal D register
number. If you need to read / write D0,
please enter 0 here.
 Other: Enter the hexadecimal actual address.
For example: Holding Register: 400100, take
0100 (decimal) that is 64 (hex).
P.S. DX supports the Holding Register :
400001~465535 (Decimal)
N/A
Device Starting Address
Set up the device starting address (decimal, input
range is from $2048 to $4095). Begin with $.
N/A
