Delta DX-2300 Series User Manual

DX-2300 Series Industrial Ethernet Cloud Router
3-26
_3
Description Default
Working Mode
Select the working mode for the current active serial port.
 Transparent mode: This mode is suitable for uploading and downloading
data remotely via the serial port.
 Slave mode: This mode is suitable for the PLC to perform the read/ write
tasks on the open register of the DX-2300LN-WW.
 Master mode: This mode is suitable for the DX-2300LN-WW to perform the
read/write tasks on the open register of the PLC.
 Close: Disable this functionality.
Close
Parameters of COM
Baud Rate
Set up the baud rate for the serial port. Options are
2400, 4800, 9600, 19200, 38400, 57600 and
115200.
9600
Data Bits
Set up the data bits for the serial port.
 Transparent mode: 7, 8
 Modbus RTU: 8
8
Stop Bits
Set up the stop bits for the serial port. Options are 1
and 2.
1
Parity Bits
Set up the parity bits for the serial port. Options are
None, Odd and Even.
None
Modbus ID
Set up the Modbus ID. The value is between 1 and 247. 1
Modbus Mode
Set up the communication mode for the device. Device support ModBus RTU
and ModBus ASCII.
ModBus RTU
Modbus Timeout
Set up the timeout timer from 200ms to 5000ms. If the set value is out of range,
it will be automatically changed to its maximum or minimum value.
200ms
Master Mode
Scan Interval
Set up the time for scan interval, ranging from 20ms
to 60000ms.
30000ms
Read/Write
Set up the access permissions for the mapped
register address;

Read-only: The device regular read data from
Read/Write
