eZV-440 Application Guide
Edition 2.6
Page 37 of 84
5. (enteliWEB only) The Output Name field displays the object's name. You can change this
name by clearing the field and entering a new name.
Setting Up a Damper Output
This topic describes how to set up damper outputs on the Local Outputs tab of the enteliZONE
configuration page.
Outputs 5 and 6 on the eZV-440 controllers are reserved for the actuator connector (1 Universal
Output, 1 TRIAC Output).
For more information about the enteliZONE algorithm's sequence of operations, go to the
Sequence of Operations topic.
Set Up a Damper Output
1. In the Function field, select the option that applies to your setup:
Function Select this option if you are:
VAV/VVT Damper_ Setting up a damper in a single duct VAV.
For a list of output configuration software objects that correspond to each function, see the
Output Configuration Objects topic.
2. In the Stage field, AirFlowDemand_ is selected automatically for VAV/VVT applications.
3. In the Control Type field, select the method of control used on the damper signal.
For more information about control types, see Control Types.
4. In the Action field, choose between direct or reverse control.
If you are using an analog actuator, in the Action field, choose between direct or reverse
control. For tri-state actuators, use the Control Type field to set the damper’s open and close
direction.
5. If you are setting up a VAV/VVT damper, in the additional settings, in the OP5-6Runtime
field, enter the amount of time it takes to move the damper from fully open to fully closed
positions.
6. If you are setting up a tri-state actuator with damper feedback, set up damper feedback on
the Local Inputs tab in the configuration page.
7. (enteliWEB only) The Output Name field displays the object's name. You can change this
name by clearing the field and entering a new name.
