Chapter 11 Summary of Parameter SettingsME300
11-23
06 Protection Parameters (1)
Pr. Explanation Settings Default
06-00 Low voltage level
115V / 230V models: 150.0–220.0 V
DC
460V models: 300.0–440.0 V
DC
180.0
360.0
06-01
Over-voltage stall
prevention
0: Disabled
115V / 230V models: 0.0–450.0 V
DC
460V models: 0.0–900.0 V
DC
380.0
760.0
06-02
Selection for over-voltage
stall prevention
0: Traditional over-voltage stall prevention
1: Smart over-voltage stall prevention
0
06-03
Over-current stall
prevention during
acceleration
Normal load: 0–150%
Heavy load: 0–200%
(100% corresponds to the rated current of the drive)
120
180
06-04
Over-current stall
prevention during
operation
Normal load: 0–150%
Heavy load: 0–200%
(100% corresponds to the rated current of the drive)
120
180
06-05
Acceleration /
deceleration time
selection for stall
prevention at constant
speed
0: By current acceleration / deceleration time
1: By the first acceleration / deceleration time
2: By the second acceleration / deceleration time
3: By the third acceleration / deceleration time
4: By the fourth acceleration / deceleration time
5: By Auto-acceleration / auto-deceleration
0
06-06
Over-torque detection
selection (motor 1)
0: No function
1: Continue operation after over-torque detection during
constant speed operation
2: Stop after over-torque detection during constant
speed operation
3: Continue operation after over-torque detection during
RUN
4: Stop after over-torque detection during RUN
0
06-07
Over-torque detection
level (motor 1)
10–250%
(100% corresponds to the rated current of the drive)
120
06-08
Over-torque detection
time (motor 1)
0.1–60.0 sec. 0.1
06-09
Over-torque detection
selection (motor 2)
0: No function
1: Continue operation after over-torque detection during
constant speed operation
2: Stop after over-torque detection during constant
speed operation
3: Continue operation after over-torque detection during
RUN
4: Stop after over-torque detection during RUN
0
