Delta ME300 Series - Fan Kit

Chapter 7 Optional AccessoriesME300
7-47
7-10 Fan Kit
Frame Fan Model Fan Kit
A MKM-FKMA
Figure 7-51
B MKM-FKMB
C MKM-FKMC
D MKM-FKMD
Fan Removal
1. As shown in the figure, press the tabs on both
sides of the fan to remove it.
2. Disconnect the power cable when removing
the fan.
Figure 7-52 Figure 7-53
Table 7-43
