Delta ME300 Series User Manual

Chapter 7 Optional AccessoriesME300
7-6
7-2 Magnetic Contactor / Air Circuit Breaker and Non-fuse Circuit Breaker
Magnetic Contactor (MC) and Air Circuit Breaker (ACB)
It is recommended the surrounding temperature for MC should be ≥ 60°C and that for ACB should be ≥
50°C. In the meanwhile, consider temperature derating for components with ON / OFF switch in
accordance with the ambient temperature of the on-site distribution panel.
115V Models
Frame Model
Heavy Duty
Output Current (A)
Heavy Duty
Input Current (A)
MC / ACB Selection
(A)
A
VFD0A8ME11ANNAA
VFD0A8ME11ANSAA
0.8 3 9
VFD1A6ME11ANNAA
VFD1A6ME11ANSAA
1.6 6 11
VFD2A5ME11ANNAA
VFD2A5ME11ANSAA
2.5 9.4 18
C
VFD4A8ME11ANNAA
VFD4A8ME11ANSAA
4.8 18 32
Table 7-5
230V Models
Frame Model
Heavy Duty
Output Current (A)
Heavy Duty
Input Current (A)
MC / ACB Selection
(A)
A
VFD0A8ME21ANNAA
VFD0A8ME21ANSAA
0.8 2.6 9
VFD1A6ME21ANNAA
VFD1A6ME21ANSAA
1.6 5.1 9
VFD2A8ME21ANNAA
VFD2A8ME21ANSAA
2.8 7.3 13
VFD0A8ME23ANNAA
VFD0A8ME23ANSAA
0.8 0.95 9
VFD1A6ME23ANNAA
VFD1A6ME23ANSAA
1.6 1.9 9
VFD2A8ME23ANNAA
VFD2A8ME23ANSAA
2.8 3.4 9
VFD4A8ME23ANNAA
VFD4A8ME23ANSAA
4.8 5.8 9
B
VFD0A8ME21AFNAA
VFD0A8ME21AFSAA
0.8 2.6 9
VFD1A6ME21AFNAA
VFD1A6ME21AFSAA
1.6 5.1 9
VFD2A8ME21AFNAA
VFD2A8ME21AFSAA
2.8 7.3 13
VFD4A8ME21AFNAA
VFD4A8ME21ANNAA
VFD4A8ME21AFSAA
VFD4A8ME21ANSAA
4.8 10.8 18
VFD7A5ME23ANNAA
VFD7A5ME23ANSAA
7.5 9 18
C
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
VFD7A5ME21ANSAA
VFD7A5ME21AFSAA
7.5 16.5 32

Delta ME300 Series Specifications

General

Power Rating	0.4 kW ~ 110 kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication	RS-485
Storage Temperature	-20-60°C
Dimensions	Varies by model
Weight	Varies by model
Input Voltage	3-phase 220VAC
Humidity	90% RH, non-condensing
