Chapter 12 Description of Parameter Settings
ME300
12.1-01-1
01 Basic Parameters

You can set this parameter during operation.
01-00
Motor 1 Maximum Operation Frequency
01-52
Motor 2 Maximum Operation Frequency of
D
efault: 60.00 / 50.00
S
ettings 00.00–599.00 Hz
 Determines the drive’s maximum operation frequency range.
This setting corresponds to the maximum value for the analog input frequency setting signal (0–
10 V, 4–20 mA, 0–20 mA, ±10 V).
01-01
Motor 1 Rated / Base Output Frequency
01-35
Motor 2 Rated / Base Output Frequency
Default: 60.00 / 50.00
Settings
00.00
–599.00 Hz
 Set this value according to the motor’s rated frequency from the motor’s nameplate.
If the motor’s rated frequency is 60 Hz, set the value to 60 Hz. If the motor’
s rated frequency is 50
Hz, set the value to 50 Hz.
01-02
Motor 1 Rated / Base Output Voltage
01-36
Motor 2 Rated / Base Output Voltage
Default:
220.0 / 440.0
Settings
115V / 230V models:
0.0–255.0 V
460V models:
0.0–510.0 V
 Set this value according to the rated voltage of the motor from the motor’s nameplate. If the
motor’s rated voltage is 220 V, set the value to 220.0 V. If the motor’s rated voltage is 200 V, set
the value to 200.0 V.
 There are a wide variety of motors, but the power system for each country is different. The
convenient and economical way to solve this problem is to use an AC motor drive, which can deal
with different voltages and frequencies, while supporting the original characteristics and life of the
motor.
01-03
Motor 1 Mid-point Frequency 1
Default: 3.00
Settings
0.00
–599.00 Hz

01-04
Motor 1 Mid-point Voltage 1
Default: 11.0 / 22.0
Settings
11
5V / 230V models: 0.0–240.0 V
460V models:
0.0–480.0 V
01-37
Motor 2 Mid-point Frequency 1
Default: 3.00
Settings
0.00
–599.00 Hz
