Delta ME300 Series - Page 217

Chapter 12 Description of Parameter Settings
ME300
12.1-01-2

01-38
Motor 2 Mid-point Voltage 1
Default
: 11.0 / 22.0
Settings
11
5V / 230V models: 0.0–240.0 V
460V models:
0.0–480.0 V
01-05
Motor 1 Mid-point Frequency 2
Default:
1.5
Settings
0.00
–599.00 Hz

01-06
Motor 1 Mid-point Voltage 2
Default: 5.0 /
10.0
Settings
11
5V / 230V models: 0.0–240.0 V
460V models:
0.0–480.0 V
01-39
Motor 2 Mid-point Frequency 2
Default:
0.50
Settings
0.00
–599.00 Hz

01-40
Motor 2 Mid-point Voltage 2
Default: 2
.0 / 4.0
Settings
11
5V / 230V models: 0.0–240.0 V
460V models:
0.0–480.0 V
01-07
Motor 1 Minimum Output Frequency
Default:
0.50
Settings
0.00
–599.00 Hz

01-08
Motor 1 Minimum Output Voltage
Default:
1.0 / 2.0
Settings
11
5V / 230V models: 0.0–240.0 V
460V models:
0.0–480.0 V
01-41
Motor 2 Minimum Output Frequency
Default:
0.00
Settings
0.00
–599.00 Hz

01-42
Motor 2 Minimum Output Voltage
Default
: 0.0 / 0.0
Settings
11
5V / 230V models: 0.0–240.0 V
460V
models: 0.0–480.0 V
 The V/F curve setting is usually set by the motor’s allowable loading characteristics. If the loading
characteristics exceeds the loading limit of the motor, you must pay more attention to the heat
dissipation, dynamic balance, and bearing lubrication of the motor.
 If the voltage is too high when the motor is at low frequencies, it may cause motor damage,
overheating, and may trigger stalling or over-current protection. To prevent motor damage or
motor fault, be careful when you set the voltage.
 The diagram below shows the V/F curve for motor 1. You can also find the V/F curve for motor 2
from the same diagram. For multi-motors selection, refer to multi-function input terminal settings
83 for Pr.02-01–02-05.
