Chapter 11 Summary of Parameter SettingsME300
11-37
10 Speed Feedback Control Parameters
Pr. Explanation Settings Default
10-16 Pulse input type setting
0: Disabled (default)
5: Single-phase input
6: PWM signal input
0
10-29
Upper limit of frequency
deviation
0.00–200.00 Hz 20.00
10-31
I/F mode, current
command
0–150% rated current of the motor 40
10-32
PM FOC sensorless
speed estimator
bandwidth
0.00–600.00 Hz 5.00
10-34
PM sensorless speed
estimator low-pass filter
gain
0.00–655.35 1.00
10-42
Initial angle detection
pulse value
0.0–3.0 1.0
10-49
Zero voltage time during
start-up
00.000–60.000 sec. 00.000
10-51 Injection frequency 0–1200 Hz 500
10-52 Injection magnitude
115V / 230V models: 100.0 V
460V models: 200.0 V
Note: The setting range varies depending on the voltage
15.0
30.0
10-53 Angle detection method
0: Disabled
1: Force attracting the rotor to zero degrees
2: High frequency injection
3: Pulse injection
0
