Delta ME300 Series User Manual

Chapter 3 InstallationME300
3-5
Frame
Airflow Rate for Cooling Power Dissipation for AC Motor Drive
Model No.
Flow Rate
(Unit: cfm)
Flow Rate
(Unit: m
3
/hr)
Loss External
(Heat sink, unit: W)
Internal
(Unit: W)
Total
(Unit: W)
C
VFD4A8ME11ANNAA
VFD4A8ME11ANSAA
16 27.2
29.1 23.9 53
VFD7A5ME21ANNAA
VFD7A5ME21AFNAA
46.5 31 77.5
VFD7A5ME21ANSAA
VFD7A5ME21AFSAA
46.5 31 77.5
VFD11AME21ANNAA
VFD11AME21AFNAA
VFD11AME21ANSAA
VFD11AME21AFSAA
70 35 105
VFD11AME23ANNAA
VFD11AME23ANSAA
76 30.7 106.7
VFD17AME23ANNAA
VFD17AME23ANSAA
108.2 40.1 148.3
VFD5A5ME43ANNAA
VFD5A5ME43AFNAA
VFD5A5ME43ANSAA
VFD5A5ME43AFSAA
60.6 22.8 83.4
VFD7A3ME43ANNAA
VFD7A3ME43AFNAA
VFD7A3ME43ANSAA
VFD7A3ME43AFSAA
75.2 30 105.2
VFD9A0ME43ANNAA
VFD9A0ME43AFNAA
VFD9A0ME43ANSAA
VFD9A0ME43AFSAA
93.1 42 135.1
D
VFD25AME23ANNAA
VFD25AME23ANSAA
23.4 39.7
192.8 53.3 246.1
VFD13AME43ANNAA
VFD13AME43AFNAA
VFD13AME43ANSAA
VFD13AME43AFSAA
132.8 39.5 172.3
VFD17AME43ANNAA
VFD17AME43AFNAA
VFD17AME43ANSAA
VFD17AME43AFSAA
164.7 55.8 220.5
Table 3-2

Delta ME300 Series Specifications

General

Power Rating	0.4 kW ~ 110 kW
Protection Features	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short Circuit
Communication	RS-485
Storage Temperature	-20-60°C
Dimensions	Varies by model
Weight	Varies by model
Input Voltage	3-phase 220VAC
Humidity	90% RH, non-condensing
