Chapter 7 Optional AccessoriesME300
7-39
Specifications:
Model Capacitance
Temperature range
CXY101-43A
Cx: 1 μF ± 20 %
Cy: 0.1 μF ± 20 %
-40– +85°C
Table 7-42
Dimensions:
CXY101-43A
Unit: mm [inch]
Figure 7-35
86.5 [3.41]
35.5 [1.40]
40.5 [1.59]
77.5 [3.05]
4.5 [0.18]
350 [13.78]
10 [0.39]
43.5 [1.71]
4.0 [0.16]
31.6 [1.24]
4.0 [ 0.1 6]
77.5 [3.05]
26.6 [1.05]
4.5 [0.18]
