Denon AVC-A1SR

ENGLISH
30
Dolby Surround Pro Logic II mode
1
Select the function to which the component you
want to play is connected.
EX:
INPUT SELECTOR
(Main unit) (Remote control unit)
2
Select the Dolby Surround Pro Logic II mode.
Select the DOLBY PRO LOGIC II mode using
the DOLBY SURROUND buttons.
DOLBY
SURROUND
(Main unit) (Remote control unit)
• The Dolby Pro Logic indicator lights.
Light
4 5, 6
1
2
2
1
4
5, 6
3
Play a program source with the mark.
• For operating instructions, refer to the manuals of the respective components.
4
Select the surround parameter mode.
Press the MODE SELECT button and “
✳ SURR.PARAMETER”.
MODE
SELECT
(Main unit) (Remote control unit)
5
Select the optimum mode for the source.
Turn the FUNCTION knob and display “MODE CINEMA”, then turn the CONTROL knob and select the
mode.
DOLBY PL II CINEMA DOLBY PL II MUSIC DOLBY PL II EMULATION
6
q Select the various surround parameters. w Adjust the parameters setting.
• DEFAULT setting
This operation cannot be performed by operating the buttons on the
main unit.
Select “Default Yes 0“, then parameters set to default setting.
(Remote control unit)
Stop pressing main unit’s buttons once you have completed setting the surround parameters. After several
seconds the normal display reappears and the settings you have made are automatically set.
NOTE:
• When making parameter settings, the display will return to the regular condition several seconds after the
last button was pressed and the setting will be completed.
Surround parameters r
Pro Logic II Mode:
The Cinema mode is for use with stereo television shows and all programs encoded Dolby Surround.
The Music mode is recommended as the standard mode for autosound music systems (no video), and is
optional for A/V systems.
The Pro Logic Emulation mode offers the same robust surround processing as original Pro Logic in case the
source contents is not of optimum quality.
Select one of the modes (“Cinema”, “Music” or “EML”).
It is possible to switch to the direct mode using the CINEMA/MUSIC button on the main unit’s panel.
Panorama Control:
This mode extends the front stereo image to include the surround speakers for an exciting “wraparound”
effect with side wall imaging.
Select “OFF” or “ON”.
Dimension Control:
This control gradually adjust the soundfield either towards the front or towards the rear.
The control can be set in 7 steps from 0 to 6.
Center Width Control:
This control adjust the center image so it may be heard only from the center speaker; only from the
left/right speakers as a phantom image; or from all three front speakers to varying degrees.
The control can be set in 8 steps from 0 to 7.
DTS NEO:6 MUSIC:
CENTER IMAGE (0.0 to 0.5: default 0.2)
The center image parameter for adjusting the expansion of the center channel in the DTS NEO:6 MUSIC
mode has been added.
FUNCTION
CONTROL
(Main unit) (Remote control unit)
(Main unit)(Main unit)
FUNCTION
CONTROL
(Remote control unit) (Remote control unit)
