Denon AVR-1508 Service Manual

150
AVR-1708/1508/688/588/488 AVC-1508AVR-688 E3 model
C1123 nsp C,CERAMIC 0.047UF-Z/50V D011473597160S
C1124-1126 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1127 00D 963 9006 544 C,ELECT 22UF-M/25V D040220084050S
C1128 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1129,1130 00D 963 9006 557 C,ELECT 220UF-M/6.3V D040221081060S
C1131 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S
C1132,1133 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050S
C1134 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1135 00D 963 0144 706 C,FILM 0.01UF-J/50V D020103167050S
C1136,1137 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1138 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C1139,1140 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1141 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1142 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050S
C1143 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1144 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S
C1145 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1146 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1147 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1148 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S
C1149 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1150 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1151 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1152 00D 963 0303 000 C,CERAMIC 0.082UF-K/50V D010823777160S
C1153 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1154 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1155 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1156,1157 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050S
C1158 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1159 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1160 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1161 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1162 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1163 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1164,1165 nsp C,CERAMIC 47PF-J/50V D010470167160S
C1166,1167 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1168 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1169 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1170 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1171 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1172,1173 00D 960 0298 802 C,ELECT 470UF-M/6.3V D040471081070S
C1174-1176 00D 963 0234 108 C,FILM 0.1UF-J/50V D020104167050S
C1177 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1178 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1179 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1180 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1181,1182 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1183 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1184 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1185 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1186 nsp C,CERAMIC 100PF-J/50V D010101167160S
C1187-1189 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1190,1191 nsp C,CERAMIC 1000PF-K/50V D011102777160S
C1192-1194 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C1198-1200 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1201,1202 00D 963 0324 403 C,ELECT 33UF-M/35V D040330085050S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
