Denon AVR-1508 Service Manual

151
AVR-1708/1508/688/588/488 AVC-1508AVR-688 E3 model
C1203-1206 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1207 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1208 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1209 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
C1210 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C1211 00D 963 0276 409 C,ELECT 100UF-M/16V D040101083090S
OTHERS PARTS GROUP
BD1001-1003 nsp COIL,BEAD MB-160808 D340160800060S
CN1001 nsp CN.WAFER 8P L101100030810S
CN1002 nsp CN.WAFER 9P L101100030910S
CP514 nsp CN.WAFER 8P L101220080010S
JACK1001,1002 00D 963 0367 709 TER,RCA 6PIN G603610D0032YS
JACK1003 00D 963 0218 001 TER,RCA 2PIN G60122001000YS
JACK1004 00D 963 0218 108 TER,RCA 3PIN G60630401000YS
L1003-1006 nsp COIL INDUCTOR 22UH D330220010520S
X1011 00D 963 0294 407 CRYSTAL 28.63636MHZ E80028R636010S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
