Denon AVR-1508 Service Manual

169
AVR-1708/1508/688/588/488 AVC-1508AVR-1508 E3 model
C752FR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C752SBL 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SBR 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SL 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SR 00D 960 9009 814 C,CERAMIC 330PF-J/50V D010331167160S
C752SW 00D 963 0350 503 C,CERAMIC 390PF-J/50V D010391167160S
C753C 00D 963 0224 008 C,CERAMIC 470PF-J/50V D010471167160S
C753FL 00D 963 0223 902 C,CERAMIC 39PF-J/50V D010390167160S
C753FR 00D 963 0223 902 C,CERAMIC 39PF-J/50V D010390167160S
C753SBL 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SBR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SL 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SR 00D 963 0223 708 C,CERAMIC 270PF-J/50V D010271167160S
C753SW 00D 963 0224 008 C,CERAMIC 470PF-J/50V D010471167160S
C755C nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755FL nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755FR nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SBL nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SBR nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SL nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SR nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C755SW nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C756C 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756FL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756FR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SBL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SBR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SL 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SR 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C756SW 00D 963 9003 194 C,FILM 0.0022UF-J/100V D02022206C060S
C803 nsp C,CERAMIC 100PF-J/50V D010101167160S
C804,805 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C806 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C809 00D 963 0293 709 C,ELECT 100UF-M/10V D040101082070S
C810 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C813 nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C814-816 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C818 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C819 nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C824,825 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C826-831 nsp C,CERAMIC 100PF-J/50V D010101167160S
C865L nsp C,CERAMIC 120PF-J/50V D010121167160S
C865R nsp C,CERAMIC 120PF-J/50V D010121167160S
C871L 00D 963 0216 304 C,FILM 0.001UF-J/100V D02010206C060S
C871R 00D 963 0216 304 C,FILM 0.001UF-J/100V D02010206C060S
C916D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C917D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C918D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C921D nsp C,CERAMIC 100PF-J/50V D010101167160S
C923D nsp C,CERAMIC 22PF-J/50V D010220167160S
C924D nsp C,CERAMIC 22PF-J/50V D010220167160S
C927D 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C928D 00D 963 9005 862 C,ELECT 47UF-M/16V D040470083080S
C931D nsp C,CERAMIC 100PF-J/50V D010101167160S
C932D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C933D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
