Denon AVR-1508 Service Manual

170
AVR-1708/1508/688/588/488 AVC-1508AVR-1508 E3 model
C934D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C935D 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C936D 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C937D nsp C,CERAMIC 1000PF-K/50V D011102777160S
C938D 00D 960 9010 010 C,ELECT 4.7UF-M/50V D0404R7087250S
C939D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C940D nsp C,CERAMIC 0.01UF-K/50V D011103777160S
C941D 00D 963 0244 606 C,ELECT 0.1UF-M/50V (Pb Free) D040R10087080S
C950D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C951D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C952D 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C953D 00D 963 0234 205 C,ELECT 10UF-M/50V D040100087070S
C954D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C955D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C956D nsp C,CERAMIC 22PF-J/50V D010220167160S
C957D nsp C,CERAMIC 0.1UF-Z/50V D011104597160S
C959D nsp C,CERAMIC 22PF-J/50V D010220167160S
BC801 00D 254 4666 005 CE04W0H105ZC(FG) D041105090010S
OTHERS PARTS GROUP
BD802-806 nsp COIL,BEAD MB-160808 D340160800060S
BD809D nsp COIL,BEAD MB-160808 D340160800060S
CN106 nsp CN.WAFER 5P L101100030510S
CN108 00D 963 0085 302 CN.WAFER 17P L101100031710S
CP01 nsp CN.WAFER 16P L101100041610S
CP301A 00D 963 0367 400 CN.FPC 35P L131524923520S
CP701 nsp CN.WAFER 19P L101100041910S
CP702 nsp CN.WAFER 15P L100912150010S
CP703 nsp CN.WAFER 8P L101100040810S
CP801 00D 963 0149 303 CN.FPC 15P L131111500010S
CP802 nsp CN.WAFER 16P L100912160010S
CP804 nsp CN.WAFER 15P L100912150010S
CP805 nsp CN.WAFER 08P L100912080010S
CP903 nsp CN.WAFER 16P L101100041610S
CP1002 nsp CN.WAFER 9P L101100040910S
JACK801 00D 963 0217 905 TER,RCA 2PIN G601206A0200YS
JACK802 00D 963 0294 601 JACK,D3.5 EARPHONE G40100350000YS
L801D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L802D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L803D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L805D nsp COIL INDUCTOR 4.7UH D3304R7000150S
L806D nsp COIL INDUCTOR 22UH D330220010050S
L807D nsp COIL INDUCTOR 22UH D330220010050S
TP803 nsp CN.WAFER 8P L101220080000S
TP804 nsp CN.WAFER 4P L101220040000S
X801 00D 963 0217 701 RESONATOR,CERAMIC ZTT12.00MT E830120000060S
OPT801D 00D 963 0237 503 MODULE JSR1165-C E100116500040S
OPT802D 00D 963 0237 503 MODULE JSR1165-C E100116500040S
Ref. No. Part No. Part Name Remarks Q'ty New

Denon AVR-1508 Specifications

General

HDMI Inputs	2
HDMI Outputs	1
Dolby Digital	Yes
DTS	Yes
AM/FM Tuner	Yes
Response Bandwidth	10 Hz - 100 kHz
Signal-To-Noise Ratio	98 dB
THD	0.08%
Input Impedance	47 kOhm
Input Sensitivity	200 mV
Tuner Type	Digital
Preset Station Qty	56
HDMI Switching	Yes
Tuning Range	FM: 87.5 - 108 MHz, AM: 522 - 1620 kHz
Audio D/A Converter	24-bit / 192 kHz
Output Impedance / Channel	8 Ohm
Frequency Response	10 Hz - 100 kHz
Channels	7.1
Power Output	75W per channel (8 ohms, 20Hz-20kHz, 0.08% THD)
Output Power / Channel	75W (8 ohms)
