Denon AVR-1611 Service Manual

122
Ref. No. Part No. Part Name Remarks Q'ty New
C461 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C463,464 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C466 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C468 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C469 nsp C,CERAMIC 100PF-J/50V D010101167160S
C470 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C471 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C472 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C474 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C476 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C477 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C479,480 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C482 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C484 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C485 nsp C,CERAMIC 100PF-J/50V D010101167160S
C486 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C487 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C488 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C490 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C492 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C493 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C495,496 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C498 nsp C,CERAMIC 0.1UF-K/50V D011104577160S
C500 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C501 nsp C,CERAMIC 100PF-J/50V D010101167160S
C502 nsp C,CERAMIC SL220PF-J/500V D00022106D051S
C503 00D9630234506 C,ELECT 47UF-M/50V (Pb Free) D040470087070S
C504 00D9630224503 C,ELECT 22UF-M/50V D040220087060S
C506 00D9609009937 C,ELECT 100UF-M/50V D040101087060S
C508 nsp C,CERAMIC 470PF-K/500V D00447127D050S
C509 nsp C,CERAMIC X7R2200PF-K/50V D011222777200S
C511,512 00D9630234302 C,ELECT 10UF-M/100V D04010008C050S
C513,514 00D9630338402 C,ELECT 330UF-M/6.3V D040331081050S
C515 00D9630324607 C,ELECT 47UF-M/10V (Pb Free) D040470082060S
OTHERS PARTS GROUP
BKT400 nsp BRACKET 0.8t/SCREW 4010210196100S
CLAMP400,401 nsp CLAMP WIRE(SOLDER) 4330000120000S
CN404 nsp CN.WIRE 5P L002251052620S *
CP401 nsp CN.WAFER 13P STRAIGHT L101200101310S
CP402 nsp CN.WAFER 5P L102526700500S
CP403 nsp CN.WAFER 10P STRAIGHT L101200101010S
CP405 nsp CN.WAFER 3P L102526700300S
G400-402 nsp CN,WIRE 1P L000600010050S *
TP401-407 nsp CN.WAFER 3P L101200100320S

Denon AVR-1611 Specifications

General

Impedance	6 Ω
Frequency range	10 - 100000 Hz
Audio output channels	5.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	98 dB
Total Harmonic Distortion (THD)	0.7 %
AM band range	522 - 1611 kHz
FM band range	87.5 - 108 MHz
Radio Data System (RDS)	Yes
Audio system	Dolby TrueHD, Dolby Digital Plus, Dolby Digital EX, Dolby Pro Logic II, Dolby Pro Logic IIx, Dolby Pro Logic IIz, DTS-HD, DTS 96/24
Output power	110 W
Dimensions (WxDxH)	434 x 381 x 171 mm
Power requirements	AC 230, 50 Hz
HDMI ports quantity	5
I/O ports	1 x Component 3 x Composite (Video) 5 x Analogue Audio (Tuner included) 1 x Composite Monitor 1 x Microphone Port 1 x Dock Control Port 1 x FM Tuner Antenna 1 x AM Tuner Antenna
Connectivity technology	Wired
Digital audio optical in	1
Product color	Black
Power consumption (standby)	0.1 W
Power consumption (typical)	360 W

Weight and Dimensions

Weight	9200 g
